E TYPE -Square Chuck Filter Cartridge

点击次数：2102次发布时间：2020-09-21

Square End Cap Filter Cartridge Square Flange Filter Cartridge - E TYPE
Model	E-PET-425*535-38100F4	E-CE-425*535-38100NFR
Size	Φ425Φ535-Φ380Φ270*1000MM
Media Type	PET-F4/260	CE-NFR/135
Filter Media	PTFE Membrane Spun bonded Polyester	80/20 Blend Cellulose with NANO Fiber Membrane & Flame Retardant
Filtration Area	30.0m2	36.8m2
Filtration Precision	0.3μm	1μm
Precision Grade	MERV16/H11	MERV14/F8
Filtration Efficiency	≥99.99%	≥99.9%
Rated Flow	≤2150m3/h	≤2200m3/h
Working Temperature	≤80℃
Initial Resistance	≤70Pa
Metal treatment	Powder spray coating metal/stainless steel mesh
★ Other changes will be depended on the demand of client.

★ CAMFIL Square End Cap Filter Cartridge

★ Alternative FARR GOLD Air Filter

★ Independently research and develop filtration materials to solve filtration problems.
